Declassified by MG Richard A. Harrison USCENTCOM Chief of Staff 811f!Jl!lftWNell10Nif Declassified on: 8 October 2025 • Aircraft Callsign I1.4a '-----.:!---~ • Radar Name or Destination~ 1.4a, 1.4g • Radar Software Load or Mission Data: SUITE 9.1 • Radar Warning Receiver (RWR) Name or Designator: ALR-56C • RWR Software Load or Mission Data: IRSWA PACER WARE • MWS Name or Designator: • MWS Software Load or Mission Data: • IRCM Name or Designator: • IRCM Software Load or Mission Data: • ECM Name or Designator: • ECM Software Load or Mission Data: • CMD Name or Designator: ALE-45 • Chaff Designator: RR-180 • Num Chaff or Cartridges: 120 • Flare Designator: MW-51/53 • Num Flares: 24 • Towed Decoy Name or Designator: • Towed Decoy Software Load or Mission Data: • Num Towed Decoys: • Type of Radar-Guided AAM: 2X AIM-120D • Num Radar-Guided AAM: 2 • Type of IR-Guided AAM: AIM-9X • Num IR-Guided AAM: 2 • Gun Name or Designator: M61Al • Num Gun Rounds: 510 • Air-to-Ground Wpn to Include Num of Each~_ _ _ _ _ _ _1_.4_a_ _ _ _ _ __ • TGT Pod Name or Designator: SNIPER-SE • Additional Avionics: • DataLink: • Gentext: ACEQUIP • Aircraft Callsign 1.4a ' - - - - - - - -..... • Radar Name or Destination: 1.4a, 1.4g • Radar Software Load or Mission Data: SUITE 9.1 • Radar Warning Receiver (RWR) Name or Designator: ALR-56C • RWR Software Load or Mission Data: IRSWA PACER WARE • MWS Name or Designator: • MWS Software Load or Mission Data: • IRCM Name or Designator: • IRCM Software Load or Mission Data: • ECM Name or Designator: 3.5c, FOIA Exemption (b)(6) MDR 25-0094 thru MDR 25-0099 / JS-250710-TM8S 10/17/25 004 Approved for Release to AARO
Vision Description (EN)
This page lists technical specifications for aircraft equipment under the heading ACEQUIP. It includes details on radar, software loads, countermeasures like chaff and flares, and weaponry. There are six specific redactions covering callsigns, radar destinations, and weapon counts, labeled with FOIA exemptions.
Descrição Vision (PT-BR)
Esta página lista especificações técnicas para equipamentos de aeronaves sob o cabeçalho ACEQUIP. Inclui detalhes sobre radar, cargas de software, contramedidas como chaff e flares, e armamento. Existem seis redações específicas cobrindo callsigns, destinos de radar e contagens de armas, rotuladas com isenções da FOIA.
