Declassified by MG Richard A. Harrison USCENTCOM Chief of Staff Bettm'l'if!fMM!f Declassified on: 8 October 2025 • Towed Decoy Software Load or Mission Data: MTP AA51 • Num Towed Decoys: 2 • Type of Radar-Guided AAM: AIM-120 • Num Radar-Guided AAM: 2 • Type of IR-Guided AAM: AIM-9X • Num IR-Guided AAM: 2 • Gun Name or Designator: M61Al • Num Gun Rounds: 510 • Air-to-Ground Wpn to Include Num of Each:l.___ _ _1_.4_a_ _ ___, • TGT Pod Name or Designator: SNIPER LDP • Additional Avionics: HTS-P R7.85 • Data Link: LINK 16 • Gentext: ACEQUIP • Aircraft Callsign: 1.4a L---,--......,....----,.....r---, • Radar Name or Destination 1.4a, 1.4g • Radar Software Load or Mission Data: 8070 / MMC 7.3 • Radar Warning Receiver (RWR) Name or Designator: ALR-56M • RWR Software Load or Mission Data: 102 / SY0730 • MWS Name or Designator: • MWS Software Load or Mission Data: • IRCM Name or Designator: • IRCM Software Load or Mission Data: • ECM Name or Designator: ALQ-184 • ECM Software Load or Mission Data: C01856 • CMD Name or Designator: ALQ-213 • Chaff Designator: RR-180 • Num Chaff or Cartridges: 60 • Flare Designator: MW-53, Mm-66 • Num Flares: 45 • Towed Decoy Name or Designator: ALE-50 • Towed Decoy Software Load or Mission Data: MTP AA51 • Num Towed Decoys: 2 • Type of Radar-Guided AAM: AIM-120 • Num Radar-Guided AAM: 2 • Type of IR-Guided AAM: AIM-9X • Num IR-Guided AAM: 2 • Gun Name or Designator: M61Al • Num Gun Rounds: 510 • Air-to-Ground Wpn to Include Num of Each:l.___ _ _1_.4_a_ _ _..... • TGT Pod Name or Designator: SNIPER LDP 3.5c, FOIA Exemption (b)(6) iECl&ll.il?JrQPQM MDR 25-0094 thru MDR 25-0099 / JS-250710-TM8S 10/17/25 004 Approved for Release to AARO
Vision Description (EN)
This document page, titled 'ACEQUIP', lists technical specifications for aircraft equipment, including radar, electronic countermeasures, and weaponry like AIM-120 and AIM-9X missiles. The page contains five small redactions, primarily covering specific weapon counts and callsigns, labeled with FOIA exemption codes 1.4a, 1.4g, and (b)(6). Classification markings 'SECRET//NOFORN' are present but struck through, and declassification information is noted in the top right corner. The document is mostly legible and contains no photos or diagrams.
Descrição Vision (PT-BR)
Esta página de documento, intitulada 'ACEQUIP', lista especificações técnicas para equipamentos de aeronaves, incluindo radar, contramedidas eletrônicas e armamentos como mísseis AIM-120 e AIM-9X. A página contém cinco pequenas redações, cobrindo principalmente contagens específicas de armas e callsigns, rotuladas com códigos de isenção da FOIA 1.4a, 1.4g e (b)(6). As marcações de classificação 'SECRET//NOFORN' estão presentes, mas riscadas, e as informações de desclassificação estão anotadas no canto superior direito. O documento é majoritariamente legível e não contém fotos ou diagramas.
